High Speed KN95 N95 2600W Ultrasonic Mask Machine

Product Description

N95 mask machine [the third generation of enhanced stability]
Model: LB-MMN95-3. 0
Manufacturer: Xuzhou Luban Intelligent Technology Co., Ltd.
1. Scope of application
KN95 mask, N95 mask
2. System composition:
N95 mask punching machine (including nose bridge machine)
N95 mask edge banding machine
N95 mask ear strap welding machine
3. System characteristics:
The third generation mask machine of N95 mask tablet machine adopts adaptive cutting technology, ultrasonic
Wave automatic frequency tracking technology greatly enhances product stability and reliability
Simple operation and quick start! Suitable for inexperienced people!
Assembled structure, can expand the number of mask layers to 5-6 layers
4. Technical parameters:
4. 1 main machine technical parameters:
Output: 40-70 tablets / minute, 60,000-100,000 tablets / day
Voltage: 220V
Power: 3300W
Size: 2.6 * 0.9 * 1.8M
Weight: 200KG
Number of floors: 4-6 floors, assembled rack, easy to add reels
4. 2 Ultrasonic technical parameters:
Voltage: 220V
Frequency: 15KHz
Power: 2600W
Size: 54 * 39 * 14CM
4. 3 Inverter technical parameters:
Voltage: 220V
Power: 750W
Current: 5A
Size: 85 * 142 * 124mm
4.4 Motor technical parameters:
Voltage: 220V
Power: 750W
Input revolution: 1400r / min
Reduction ratio: 15
Form: Coaxial
5. Operation process
1. Start-up steps: make sure the material feeding and paralleling are completed, connect to the 220V power input, unlock the "reset" button, start the main power switch of the control box, and immediately start the ultrasonic power switch, and the equipment runs.
2. Shutdown steps: first turn off the ultrasonic power switch, turn off the main power switch of the control box, and then press the "emergency stop" button to cut off the main power input and the device is turned off.
3. Emergency Suspend: When a special situation occurs, immediately press the "Emergency Stop" button and the device will pause.
6. Configuration list:
Ultrasonic * 1 set
Frequency converter * 1
Gear reducer motor * 1
Film rolling system * 1 set
Feeding rack * 1 set
Control box * 1
