Gps Odm Remote Control 500m Water Rescue Robot TS3 For Reservoirs

Minimum Order Quantity : 1 Packaging Details : Customized box
Payment Terms : T/T, L/C, Western Union Supply Ability : 10sets/month
Place of Origin: China Brand Name: Topsky
Model Number: TS3

Detail Information

Screen: 12inch High Light LCD Screen Size: 1032 × 630 × 200 Mm.
Weight: 13.5KG Image System: 360°panorama Image System
Wireless Control Distance: 500m Wire Control Distance: 1000m
High Light:

odm water rescue robot

,

500m water rescue robot

,

gps water rescue robot

Product Description

Water rescue remote control robot TS3



Overview



As a small surface rescue robot that can be operated by remote control, TS3 can be widely used for water rescue in swimming pools, reservoirs, rivers, beaches, yachts, ferries, floods and other scenes.

The remote control is realized by the remote control, the operation is simple, and the travel route of the lifebuoy can be accurately controlled. No-load speed is greater than 6m/s, it can quickly reach the person who fell into the water for rescue, and the manned speed is 2m/s. There are high-penetration signal warning lights on both sides, which can easily locate the position of the lifebuoy at night and in bad weather. The front anti-collision strip can effectively prevent collision and injury to the human body during the travel. The propeller adopts a protective cover to prevent foreign objects from entanglement. The TS3 is equipped with a camera stand on the front side, which can be installed to record rescue information. The lifebuoy has a built-in GPS/Beidou dual positioning system, which can achieve precise positioning.



When a falling water accident occurs, you can use TS3 to accurately locate the location of the person who fell into the water through GPS positioning, video recognition, manual identification, etc., and use the remote control to control the location of the person who fell into the water to start rescue. The person who fell into the water can easily grab the lifebuoy for falling into the water People wait for rescue, or bring the overboard to a safe area through the power system, which gains precious time for rescue and greatly improves the survival rate of overboard personnel. When the person falling into the water is in critical condition, TS3 can carry rescuers to quickly approach the person who fell into the water for rescue. This kind of application not only saves the precious physical strength of rescuers, but also greatly improves the rescue efficiency. When long-distance rescue (outside the visible range) is required, TS3 can cooperate with drones to carry out three-dimensional rescue. This three-dimensional intelligent unmanned rescue system combining air and water greatly increases the scope of rescue and greatly enriches rescue methods.

Scope of application

Swimming pools, Reservoirs, Rivers, Beaches, Yachts, Ferries, Floods rescue

Feaures

  • Reliable shell: Use LLDPE material with good wear resistance, electrical insulation, toughness and cold resistance.
  • ★Accurate positioning: Support GPS/Beidou dual positioning system, positioning faster and more accurate.
  • ★Return to home system: One-key automatic return to home function, automatic return to home function when lost connection.
  • ★Clear recognition: High-penetration warning lights can determine the location of the equipment even in foggy weather.
  • ★Self-righting: With self-righting function, it can be automatically righted to normal driving after overturning.
  • ★Controllability: Remote control operation can perform basic actions such as forward, backward, left turn, right turn, and automatic return to home.
  • ★Network (optional video, audio): Connected to the robot networked cloud platform, real-time status information such as the robot's location, power, audio, video, detection information, etc., can be transmitted to the cloud through the 4G/5G network, and the background PC and mobile terminals can be consulted
  • ★The hull is light and easy to put out quickly: Lightweight hull, easy and quick to release

Technical parameters:

  • Dimensions: 930mm*760mm*270mm
  • ★Weight: ≤13Kg
  • ★Rescue load capacity: ≥400Kg
  • Maximum thrust: ≥300N
  • ★Return home accuracy≤2m
  • No-load speed: 6.3m/s
  • Manned speed: 2m/s
  • ★Low-speed endurance time: ≥60min
  • ★Remote control distance: ≥1.6Km
  • Provide buoyancy: ≥25Kg
  • Remote control life time: ≥3h

product configuration:

1. Water rescue remote control robot ✖1

2. Handheld remote control ✖1 set

3. Robot charger ✖1

4. Robot battery cover removal tool ✖1
