High Efficiency Double Foot Bipedal Humanoid Robot For Firefighting Emergency

Minimum Order Quantity : 1 set Price : USD4000-5000/Set
Delivery Time : 15 working days Payment Terms : T/T
Supply Ability : 1Set
Place of Origin: China Brand Name: TOPSKY
Model Number: LT-BMXT

Detail Information

Name: Double -foot Robot Net Weight:: 22.9kg
Creek Height:: 540x371x270mm Standing Maximum Load:: 4KG
Maximum Communication Distance:: 2km Stand At Low Speeds: ≥40min
High Light:

high efficiency bipedal humanoid robot


firefighting bipedal humanoid robot


emergency bipedal robot

Product Description

Double -foot robot LT-BMXT




1.Product description
This double foot robot is a two -footed balance -type mobile robot equipped with power wheels. This robot can combine the speed advantage of wheeled robots and combined with the maneuver obstacles of foot robots, which can be efficient and flexible in multi -terrain. This robot is also a hot spot for academic research now. The legs and body structure of the robot are independently developed and designed at the end of this technology, and a total of six direct -drive joint motors M1502D.
Applicated in the firefighting and emergency field

Easy to maintain: Because there is no loss of the transmission structure, the life span of the direct drive scheme is longer and the system is more stable and reliable. The flange connection design also makes the maintenance and maintenance of the equipment simple and easy.

High efficiency: Because there is no friction of the transmission mechanism, the direct drive solution has higher power utilization efficiency, which can provide 30%of the battery life improvement. The equipment can have more time to invest and work less time to return to charge, and the cost recovery speed has increased significantly.

Higher space utilization: Modular design makes product solution design more efficient. The design cycle of the chassis of the wheel robot is shortened by at least 20%. It can cope with the challenges of various complex needs, and enterprises can be more calm in the development time.

4.Main Specifications

1.Power adapter parameter

1. Output current: 8A

2. Output voltage: 33V

3. Input voltage: 220VAC

2. motor parameters

1. Motor size: Zhong 144X41.8

2. Electric weight: 2.3kg

3. Work voltage: 28-32V

4. Rated voltage: 32V

5. Cover current: 21A

6. Rating current: 12A

7, rated torque: 9.6nm

8. Rating speed: 115rpm

9.Coder resolution: 15 bits

3.Robotic parameter

1.Net weight: 22.9kg

2. Standing length, width, height: 540x371x491mm

3. Creek height: 540x371x270mm

4. Standing maximum load: 4KG

5. Maximum load:> 80kg

6. Running noise: <49dB

7. Main control model: Raspberry Pi4

8. Operating system: Ubuntu Mate

9. Maximum continuous standing time: When the ambient temperature is 25 ° C, the standing time is ≥90min

10. Maximum consecutive movement time: When the ambient temperature is 34 ° C, the hip high -speed travel time is 4H

11. Maximum continuous standing forward time: When the ambient temperature is 34 ° C, stand at low speeds ≥40min

12. Jump height: Under empty load, the jump height is about 8cm

13. Maximum travel speed: 1.6m/s (under the state of creeping)

4.remote control

1. Maximum communication distance: 2km

2. Receiving sensitivity: -104dbm

3. Output frequency: 2.4GHz

4. Maximum security remote control distance: 150M

5.Battery parameter

1. Battery type: lithium battery

2. Capacity: 170Wh

3. Circular life: Maintain more than 80%of the initial capacity after 1000 cycles


High Efficiency Double Foot Bipedal Humanoid Robot For Firefighting Emergency 0
