LTMS 2.0 Laser Displacement And Tilt Angle Monitor With Wireless Remote Control

The LTMA2.0 laser remote displacement monitor is a combination of harmless laser and tilt Angle detection, which can accurately detect any subtle movement of dangerous buildings and other building structures (such as floors, floor tiles, columns, walls) caused by earthquakes, bombs, gas explosions, etc.

Laser monitoring: harmless laser, with sound and light alarm function, support wireless remote control, two-way wireless transmission, can accurately measure the displacement of walls and other targets and alarm.

Tilt monitoring: with displacement Angle change monitoring function, while with voice alarm and magnetic function, and support wireless remote control, two-way wireless transmission.

Equipped with portable host, support wireless remote control, two-way wireless transmission, adjustable and reset monitor alarm value, linkage alarm. With GPS positioning and one-click search function, when the inclination monitor is buried in the rubble, it can be searched by one-click search.

l Earthquake relief

l Rescue at the scene of the explosion

l Hazardous accident rescue

l Land rescue: applicable to civilian, police, military, fire, high-rise or mountain stream rescue occasions

l 1. Dual screen display

l Laser: real-time detection of displacement distance;

l Video: video detection target, can be enlarged, reduced, can take photos, video;

l 2. Combination of displacement and tilt monitoring

l Precise monitoring of small movements in current areas such as buildings;

l High precision stereo monitoring Angle change;

l 3. High precision stereo monitoring

l Three-dimensional monitoring of X, Y, Z triaxial Angle changes;

l Detection accuracy up to 0.01°;

l 4. Remote control

l Equipped with handheld portable mainframe;

l Adjust and reset the alarm value of the monitor;

l Linkage alarm with monitor;

l 5.★ Location search

l GPS positioning function, can display the relative orientation of each monitor and the host;

l One key to find the inclination monitor, and through the probe voice broadcast function to distinguish signal sources;

l 6. Audible and visual alarm

l Exceed the set value, high decibel, high brightness sound and light alarm (mute);

l Voice alarm (mute);

l 7. 4G function

l Check the working status in real time through computer, tablet and mobile phone;

l Access to the cloud platform: display detection information, electricity, GPS positioning and other information;

4.1 Laser displacement monitor

1. LCD screen: video display 4.3 inch color screen, laser display 0.96 inch OLED screen;

2.★ Working mode: slow/fast switch;

3. Detection accuracy: 1mm, resolution 0.1mm;

4. Detection distance: 0-100m(detection distance will decrease with the enhancement of light);

5. Alarm threshold:

a) Quickly set 8 stops: 5, 10, 15, 20, 30, 50, 70, 80mm;

b) User-defined: 1-999mm;

6. Sound and light alarm function:

a) Alarm brightness: ≥1000 lumens;

b) Alarm volume: ≥120DB (mute);

c) Voice alarm: displacement, too close, too far, abnormal observation, low power alarm;

7.★ Video:

a) Independent switch, can be turned on and off;

b) Zoom in and out, 36 times;

c) Take pictures and videos, can be exported;

8.★ Store video information: 32G memory card, support export;

9. Auxiliary detection: sight, laser light and telescope;

10. Battery: 12V 10AH;

11. Working hours: ≥15 hours;

12. Environmental information:

a) Operating temperature: -15℃ to +55℃;

b) Storage temperature: -40℃ to +70℃;

4.2 Inclination monitor

1. Measurement accuracy: 0.01°, resolution: 0.01°;

2. Detection range: x axis, y axis: -180°-180°, z axis: -90°-90°;

3. Call the police:

a) Low displacement, electricity alarm;

b) Voice alarm: mute;

c) Alarm volume: ≥120DB;

4. Synchronous work: four detectors work synchronously;

5. Auxiliary functions:

a) Boot self-test;

b) Low voltage alarm;

c) Insert needle at the bottom;

d) Bottom magnetic absorption;

6.★ Working time: ≥15 hours;

7. Environmental information:

a) Operating temperature: -15℃ to +55℃;

b) Storage temperature: -40℃ to +70℃;

4.3 Portable Host

1.★ Large 10 inch color LCD display, resolution 1920*1080;

2.★ Equipped with a wrist strap can be held in one hand, there is a strap can be carried in a backpack, free hands;

3. Communication distance: the communication distance between the host and the displacement monitor and the inclination monitor should be ≥800 meters (open area);

4. The host real-time display of laser displacement monitoring status: distance, displacement, threshold, connection status, alarm status, battery power indicator;

5. The host real-time display inclination monitoring status: X, Y, Z axis Angle change, threshold, connection status, alarm status, battery power indicator;

6.★ Two-way control:

a) Adjust and reset the alarm value of the monitor;

B) Angle quickly set up 3 files: 0.3 ° and 0.5 ° and 1.0 ° and 2.0 ° and 4.0 ° and 6.0 ° and 8.0 °, 10 °.

c) Angle user-defined: 0.1-30°;

d) Control quantity: 4 inclination monitors;

e) Laser quick setting 8 stops: 5, 10, 15, 20, 30, 50, 70, 80mm;

f) Laser user-defined: 1-999mm;

7. Synchronous alarm: monitor displacement, low pressure alarm, host synchronous alarm prompt and monitor linkage alarm;

8.★ One-key search: one-key search inclination monitor, and distinguish signal sources through the probe voice broadcast function;

9. The device has GPS positioning function, which can display the relative orientation and distance between the monitor and the host;

10. Storage displacement information: 8G memory card, can store 30 million, support export CSV table;

11.★4G features:

a) Check the working status in real time through computer, tablet and mobile phone;

b) Access to the cloud platform: display detection information, electricity, GPS positioning and other information;

12. Auxiliary lighting: the main engine has two built-in lighting, lighting function;

1. Battery: 12V

2. Working time: ≥13 hours;

3. Environmental information:

a) Operating temperature: -20℃ to +55℃;

b) Storage temperature: -40℃ to +70℃;
