RB101 Phased Array Gsr Radar With 2.5km Detection
RB101 Phased Array Gsr Radar With 2.5km Detection RB101 Phased Array Gsr Radar With 2.5km Detection RB101 Phased Array Gsr Radar With 2.5km Detection
Contact Now

RB101 Phased Array Gsr Radar With 2.5km Detection

Minimum Order Quantity : 1 set Price : USD15000-USD25000
Packaging Details : Export package Delivery Time : 30 days
Payment Terms : T/T Supply Ability : 200 Sets/Month
Place of Origin: China Brand Name: TOPSKY
Model Number: RB101

Detail Information
Name: Counter Terrorism Equipment RB101 Phased Array Ground Radar With 2.5km Detection Work System: Phased Array System (azimuth Phase Scan)
Operating Mode: Pulse Doppler Working Frequency: C Band (5 Working Frequency Points)
Maximum Detection: ≥1.5km（pedestrian） ≥2.5km（vehicle）
High Light:

2.5km Detection Gsr Radar

,

Phased Array Gsr Radar

,

Gsr Radar With 2.5km Detection

Product Description

RB101  Security Surveillance Radar



1. Product function and use

XW/RB101 security surveillance radar is mainly composed of a radar array and a power adapter. It is used for the detection, alert and target indication of pedestrians and vehicles in key areas such as borders, airports, and military bases. It can accurately give the target's position, distance and Track information such as speed.

  • Main specifications



ITEM Performance parameters
Work system system (azimuth phase scan)
Operating mode Pulse Doppler
Working frequency C band (5 working frequency points)



Maximum detection distance

≥1.5km(pedestrian)

≥2.5km(vehicle)
Minimum detection distance ≤ 100m
Detection range

Azimuth coverage:30°/ 45°/90°(Configurable)

Elevation coverage:18°
Detection speed 0.5m/s～30m/s



measurement accuracy

Distance accuracy:≤ 10m

Bearing accuracy:≤ 1.0°

Speed accuracy:≤ 0.2m/s
Data rate ≥1 times /s (30°)
Peak output power 4W/2W/1W(Configurable)
Data interface RJ45,UDP
Power and power consumption

Power consumption:≤35W

power supply:AC 220V(Power adapter)



working environment

 Operating temperature:-40℃～60℃； Storage temperature:-45℃～65℃；
Outside size 324mm×295mm×120mm
Weight ≤4.0kg

1) Note:

2) 1) There are many options for azimuth coverage, and different azimuth coverage has different data rates.

3) The peak output power can be configured online, and the maximum output is 4W.
