UWB 30m Detection Distance Life Detector 100m Wireless Transmission

Minimum Order Quantity : 1 Set Delivery Time : 10 working days
Payment Terms : T/T, Western Union Supply Ability : 50 Sets/Month
Place of Origin: China Brand Name: TOPSKY
Model Number: YSR

Detail Information

Name: 30m Detection Distance 100m Wireless Transmission Life Resuce Detector Detection Distance: Greater Than 30m
Penetrating Ability: The Thickness Of The Brick-concrete Structure Solid Wall Is Greater Than 50cm; Number Of Detections: Detect More Than 3 Living Organisms At One Time
Explosion-proof Grade: Exib IIC T6 Gb
High Light:

30m Detection Distance Life Detector

,

100m Wireless Transmission Life Detector

,

UWB Life Detector

Product Description

30m detection distance 100m wireless transmission Life Resuce Detector



YSR Radar Life Locator uses ultra wideband (UWB) radar technology to improve the odds of rescue following structural collapses due to weather, fire or catastrophic attack, avalanches, flash floods, earthquakes or other natural disasters. The life locator is ideally suited for life rescue, locating victims by sensing even the minor movements of shallow breathing. The working range is over 25m. YSR Radar life locator has proven to be an effective tool in detecting life signs like breathing and movement at building collapse locations.



It is consist of Radar sensor and PDA. The Radar transmit the data to PDA via WIFI. And the operator can read the detect info on PDA. It is farther range, high resolution and easier use than other devices.



UWB 30m Detection Distance Life Detector 100m Wireless Transmission 0

UWB 30m Detection Distance Life Detector 100m Wireless Transmission 1





Application:





The YSR life locator can be widely used in earthquake ,avalanches, flash floods or other natural disasters.





Features:





Portable and lightweight



Excellent detection range



Work in tough situation



Easy operation, no need professional training



Easy to deploy



Low power requirement





Specification:





Type Ultra wideband (UWB) radar
Motion detection: up to 25m

Breathing detection: up to 20m
Accuracy: 10CM
PDA SIZE: 7 inch LCD
Wireless range: up to 100m
Windows system: windows mobile 6.0

Start up time: less than 1 minute

Battery time: up to 10h
