Underwater Sonar Rescue 20m Life Detector Aluminum Alloy

Minimum Order Quantity : 1 set Price : USD10000-USD15000
Packaging Details : Export package Delivery Time : 15 working days
Payment Terms : T/T, Western Union Supply Ability : 200 Sets/Month
Place of Origin: China Brand Name: TOPSKY
Model Number: V8

Detail Information

Name: Underwater Sonar Life Rescue Detector Underwater Camera: 2.LCD Screen Size: 7 Inches (optional 9 Inches, 10 Inches, 13.3 Inches)
Monitoring Depth: 3. 20m (optional 20m, 50m, 100m) Materia: Aluminum Alloy
Sonar Host: Sounding Depth: 300 Meters Imaging Depth: 91 Meters
High Light:

Sonar life detector


20m Life Detector


aluminum alloy life detector 20m

Product Description

Underwater Sonar life Rescue Detector


Scope of application

1. Target detection

lDisplay sonar image

lDisplay video images

2. Probe information

lThe distance and location of the target point, water temperature, water depth and GPS latitude and longitude information

l360-degree automatic rotation real-time detection

3. Probe storage

lSave waypoints, tracks and routes

lStore distance and position information, location information and time

4. Probe playback

lReplay of stored detection information

lView the detection trajectory and the location of the target point

5. Alarm function

lLost, dangerous and fault alarm

lMultiple alarm modes

6.WIFI function

l WIFI transmission equipment information

l View data in the background


七,the main technical indicators


4.1 Underwater camera:

1. ★LCD screen size: 7 inches (optional 9 inches, 10 inches, 13.3 inches)

2. ★Monitoring depth: 20m (optional 20m, 50m, 100m)

3. ★Resolution: 1920*1080

4.★Light source: 20 white light lamps, 18 infrared lamps (manually turn on and off)

5.★Control: autorotation, left turn, right turn (360°rotation)

6. Battery: 12V 4500MA

7. Battery life: 6-8 hours (real-time reminder of power)

8. Material: aluminum alloy

9. Working temperature: -20-60℃

10. Storage temperature: -30-80℃

4.2 Sonar host:

1. LCD screen size: 7 inches

2. Resolution: 1024*600

3. Interface: multi-touch screen + button type

4. ★ Imaging depth: 91 meters

5. ★Sounding depth: 300 meters

6.★Radar compatibility: 4G/3G/radar antenna

7. Built-in CHIRO fish finder, structure scanning, GPS antenna, global simple map, wireless WIFI

8. With dual-channel CHIRP sonar, sonar and imaging records, historical playback, water temperature display, target recognition and alarm, split-screen display

9.★Support detailed chart, audio connection, autopilot, IPAD wireless display, 3D stereo imaging

10. Number of waypoints stored: 3000

11. Number of routes stored: 100

12. Number of tracks stored: up to 10,000 points each

13. Display brightness: greater than 1200Nits

14. Installation method: bracket type, embedded

15. Battery: 12V 32AH

Protection level: IPX7
