Small Size Heavy Load Dismantling Drone Flight Duration Modular Design

Minimum Order Quantity : 1set Price : USD25000
Packaging Details : Aluminium case Delivery Time : 60days
Payment Terms : T/T Supply Ability : 10sets/month
Place of Origin: China Brand Name: Topsky
Model Number: LT-400-PC

Detail Information

Payload Flight Time: 22min Model Structure: 4-axis
Diagonal Wheelbase: 1000mm Drone Deployment Time: 2min
Maximum Payload: 5kg Maximum Takeoff Weight: 18kg
Maximum Payload Flight Time: 25min Maximum Flight Speed: 20m/s
Highlight:

Small Size Dismantling Drone

,

Heavy Load Dismantling Drone

,

Modular Design Dismantling Drone

Product Description

Dismantling unmanned aerial vehicle



I. Product Overview




Dismantling UAV is an industrial-grade drone designed for high-altitude, high-risk and complex environments, equipped with the world's first electroless cutting pen technology, breaking through the dependence of traditional cutting tools on power supply and operation space, and achieving safe, efficient and pollution-free remote precision cutting operations. It is suitable for power maintenance, high-altitude rescue, industrial maintenance, military emergency and other multi-scenario needs, and redefines the new standard of high-altitude cutting operations. The main body of the demolition drone is made of carbon fiber, the arm can be folded quickly, and the whole machine is light in weight and small in size, which is easy to carry and quickly deploy. The no-load endurance of the whole aircraft is more than 45min, and the ultra-long endurance can meet most of the application fields. The firefighting drone is equipped with RTK and millimeter-wave radar, which can achieve centimeter-level positioning accuracy and obstacle avoidance capabilities.



II. Scope of Application



Fire emergency

Electricity emergency repair

High-altitude rescue

Industrial maintenance



III. Product Features

  1. 1. Small size

    The arm and propeller blades are foldable, occupying less space after folding;

    2. Heavy load

    The maximum load that can be mounted is 5kg;

    3. Flight duration

    Equipped with a large capacity battery and efficient motor, the fully loaded flight time is greater than 20 minutes;

    4. Widely applicable:

    It can be used in fire emergency, power repair, high-altitude rescue, and industrial maintenance

    5. Modular design:

    The pen can be quickly disassembled and assembled, and is compatible with other work modules (e.g. inspection cameras, spraying devices).

IV. Main Technical Indicators



  1.


    Dismantling UAV

    1. Model structure: 4-axis

    2. Power source: Lithium battery (soft pack battery)

    3. Diagonal wheelbase: 1000mm

    4. Body Material: Carbon Fiber

    5. Drone deployment time: ≤ 2min

    6. Positioning and Navigation: RTK+GPS

    7. Control radius of data communication link: ≥ 15km

    8. Transmission distance of image and video links: ≥ 15km

    9. Maximum takeoff weight: 18kg

    10. Maximum payload: 5kg

    11. Empty flight time: ≥ 45min

    12. Maximum payload flight time: ≥ 25min

    13. Maximum flight speed: ≥ 20m/s

    14. Maximum climb speed: ≥ 6m/s

    15. Maximum descent speed: ≥ 3m/s

    16. Maximum wind resistance: ≥ Level 5 (Instantaneous Level 6)

    17. Cruise altitude for homework: 20-1000 meters

    18. Camera: Front facing high-definition camera

    19. Obstacle avoidance radar: front and rear obstacle avoidance distance of 1-20 meters

    20. Battery: 1 set of 30000mah

    21. Protection level: IP45

    22. Working temperature: -20 ℃ to 50 ℃

    23.The burning temperature of the cutting operation:2800~3000℃
