Product Description
Earthquake search robot single arm
1,Product Overview
Main functions: It is used to replace manual operation in approaching flammable, explosive, complex and other harsh environments to conduct environmental reconnaissance, gas detection and other operations. It can also be used to reconnaissance small and low spaces such as the bottom of the vehicle body and the bottom of the shelf.
Application scenarios: reconnaissance of toxic gas factories, forests, earthquakes, mines and other collapses.
System composition: It mainly consists of three parts: remote control, vehicle body and mounting. The remote control controls and displays the video data information sent back by the vehicle body; the vehicle body is mainly responsible for mounting.
2,Scope of Application
Reconnaissance: urban fire reconnaissance,forest fire reconnaissance
Rescue: Earthquake rescue,mine rescue,collapse rescue,traffic rescue
3,Product Features
1,10-inch touch screen
High-definition anti-glare,photo taking,video recording,storage,playback
2,Wireless transmission (optional)
WiFi,Hot Spots,4G transmission
4,Technical parameters
4.1 Robot:
Used to provide unmanned search and rescue function at the rescue site. Protection level ≥IP67, ground clearance ≥100mm, obstacle height ≥200mm, climbing gradient ≥40°, can realize autonomous obstacle avoidance, autonomous navigation, autonomous alarm, audio and video feedback, etc.
1. Basic functions: personnel search,video reconnaissance function,gas detection,small mass (≤5kg) material transportation
2. Walking mode: crawler + front swing arm walking mechanism, rotating in place
3. Protection level: The protection level of the robot body is IP67 [This parameter is consistent with the inspection report of the national inspection agency]
4. Power: electric, ternary lithium battery (automatically detects short circuit,
overcharge and over-discharge and cuts off power)
5. Size: ≤ length 610mm × width 490mm × height 220mm (excluding antenna)
6. Weight: ≤25kg [This parameter is consistent with the inspection report of the national inspection agency]
7. Maximum straight-line speed: ≥5.4Km/hour (≥1.5m/s), remote control stepless speed change [This parameter is consistent with the inspection report of the national inspection agency]
8. Straight deviation: ≤5% [This parameter is consistent with the inspection report of the national inspection agency]
9. Gradability: ≥43° [This parameter is consistent with the inspection report of the national inspection agency]
10. Stair climbing ability: ≥32° [This parameter is consistent with the inspection report of the national inspection agency]
11. Obstacle crossing height: ≥260mm [This parameter is consistent with the inspection report of the national inspection agency]
12. Ground clearance ≥50mm
13. Continuous walking time: ≥2h
14. Wireless video transmission distance: ≥400m (open) two-point communication; ≥800m (open plus relay) three-point communication, to meet the occlusion scene; [This parameter is consistent with the inspection report of the national inspection agency]
15. Wired control and video transmission distance: ≥100m [This parameter is consistent with the inspection report of the national inspection agency]
16. Camera: Front high-definition camera, which can simultaneously view and control the movement status of the vehicle
