IP68 Protection Level Self-suction Fire-fighting Robot with 20.5m Maximum Operating Height and 30.3L/s Maximum Flow Rate

Product Description

• Product Overview
• The M20D self-suction fire-fighting robot is a wheeled multi-functional robot that integrates remote control, independent water collection, fire extinguishing, smoke suppression, cargo carrying, self-water spraying for cooling, fire eye recognition, environmental perception, image capture, working lighting, outline lights, warning lights, and off-road movement.
• Product Features
• It can perform fire-extinguishing and flood-draining operations. It can achieve automatic water-following, drainage-following and remote water-supply functions. The maximum drainage flow rate is ≥ 93 m³/h.
• Detection of multiple gas environmental parameters
• 4G wireless transmission system, which can synchronously transmit video and environmental monitoring data to the command center via network, achieving a "trinity" fire command system.
• Technical parameters
• Adopt ATV hydraulic rubber tracked chassis
• Traction force: 35KN
• Dragging distance: ≥ 100m (dragging four DN80 full water hoses)
• Travel speed: ≥ 1.2/s, remote control with stepless speed adjustment
• Climbing ability: ≥ 62%
• Pushing force of the shovel: ≥ 35KN
• Shovel pitch angle: Pitch angle ≤ 0°, Pitch angle ≥ 30°
• Continuous travel time: ≥ 2.5h
• Range of operation: ≥ 6h
• Remote control distance: 1. 1km (visible distance, affected by the actual environment)
• Control method: Wireless remote control
• Obstacle clearance ability: 230mm obstacles; can adapt to grassland, sandy land, snow land, gravel, mudflat and other environments
• Water depth: Up to 460mm
• Straight running deviation: < 6%
• Lifting height: 4700mm
